Detail drawings I love

@archnodi6

7.1K followers · usually 354 views a post

Views

16.0K

Likes

1.7K

Comments

3

Shares

40

SoundTikTok sound · original sound - tgold

Promoted product

Nodi's 1st Event

Hi guys!! This has been a long time coming and I think it’s finally time to host a meet up so that you can all get to know each other and most importantly connect. I love surrounding myself with other designers and creatives so let’s just have a fun time. I’m working on app for designer specific networking and this first event is just to see who might to interested in something like that.

Why it worked

The post likely performed well due to its high-quality, detailed architectural visuals which appeal to a niche audience interested in design and construction. The use of a specific event as the promotional focus, coupled with a clear bio link, makes it easy for interested viewers to take the next step.

Summary

This post showcases detailed architectural drawings and renderings, highlighting various construction elements and design concepts. It appears to be an invitation or advertisement for an event related to these architectural designs.

Structure

1Introduction to detailed architectural drawings
2Showcase of structural elements and sections
3Presentation of facade and interior renderings

Original caption

#design #designinspo #ArchNodi

More from @archnodi6

Product placement

The video promotes 'Nodi's 1st Event' via a Partiful link in the creator's bio.

Call to action

The call to action is implied by the event promotion and the link in the bio.

On-screen text

Detail drawings I love sezione di dettaglio 1:20 Prospetti di dettaglio 1:20 1. STRUTTURA: magrone in calcestruzzo cm 10 dado di fondazione B.C.A. cm 40 armatura in acciaio ad alta aderenza mm colonna 6 T in acciaio verniciato 2. SOLAIO CONTROTERRA: magrone in calcestruzzo cm 10 membrana armata con igraide e cappa privata cm 30 guaina impermeabilizzante autoadesiva materasso additivato per pavimenti isolanti cm 8 paravento in cernesto industriale pigmentato in pasta lucidato cm 5 3. SOLAIO DI COPERTURA: manto di copertura in lastre di lamiera pre-verniciata barriera al vapore e al calore cm 3,5 guaina impermeabilizzante paravento OSB mm 18 coibentazione in lana di roccia cm 18 e barriera al vapore paravento in cartongesso cm 15 e rasatura in cernesto 4. PARTE ESTERNA: rivestimento in ceramica cm 5 paravento in ligrannito cm 5 barriera al vapore in lana di roccia cm 18 e barriera al vapore paravento in cartongesso mm 15 e rasatura in cernesto e smalto 3. SERRAMENTI ESTERNO: legno lamellare con finitura verniciata color bronzo Prospetto dettaglio 1:50 Sezione dettaglio 1:50 Potager Bac en bois Substrat Vitrage Menuiserie bois Blocs pierre massive isolation laine de bois Plaque plâtre Couvertine Accrotère Mise à distance végétale Lames bois Solives Étanchéité Pare vapeur Nez de dalle béton Voilage Baudauge garde corps Lames bois Solives Plots Pissette Étanchéité
