Why it worked

The video provides practical, actionable advice for a common and frustrating automotive diagnostic problem. By breaking down the troubleshooting process into clear, numbered steps, it empowers viewers to diagnose issues themselves, making it highly shareable and valuable content.

Summary

This video explains how to diagnose U-codes, which indicate network communication faults in a car. It advises checking power and grounds first, then looking for specific modules that might be offline, and finally checking fan speed as an indicator of a network issue.

Structure

1Introduction to U-codes
2Connecting the scan tool
3Interpreting scattered U-codes (network issue)
4Interpreting localized U-codes (module issue)
5

Original caption

Turning brake rotors without measuring them first can create bigger problems than the ones you're trying to fix. Many modern brake rotors have very little material between new thickness and discard thickness. One pass on the brake lathe could push them below spec. At Master Automotive Training in Rancho Cucamonga, California, we teach technicians how to use service information, specifications, and proper testing procedures to make the right repair decisions every time. 📍 Rancho Cucamonga, CA 🔧 Automotive Technician Training 👉 Register now: https://campscui.active.com/orgs/MasterAutomotiveTraining?orglink=camps-registration# #MasterAutomotiveTraining #BrakeRepair #BrakeRotors #AutomotiveTraining #RanchoCucamonga #MechanicTraining #BrakeService #AutoTech #AutomotiveDiagnostics #CaliforniaTechnicians

More from @masterautotraining

Product placement

MAT MASTER AUTOMOTIVE TRAINING ACTS - it is a training company that teaches automotive repair. Removing it would change the context of the video. FOXWELL ACTS - it is a scan tool used to read diagnostic codes from a car. Removing it would change what happens in the video.

On-screen text

U-CODES ALL OVER THE A SCREEN SHOULDN'T STOP YOU HERE'S HOW TO READ THEM CAR COMES IN YOU CONNECT THE SCAN TOOL U-CODES EVERYWHERE EVERY MODULE SEEMS TO HAVE A COMMUNICATION FAULT MOST TEXTS FREEZE RIGHT THEN AND THERE THIS IS ACTUALLY WHERE STARTS NETWORK COMMUNICATION FAULTS THEY DON'T MEAN EVERY MODULE HAS FAILED THEY MEAN THE MODULES AREN'T TALKING TO EACH OTHER THE WAY THAT THEY SHOULD AND HERE'S HOW TO READ THE PAGE FULL OF U CODES FIRST LOOK FOR THE PATTERN IF U CODES ARE SCATTERED ACROSS EVERY MODULE THE PROBLEM IS THE NETWORK NOT THE MODULES START AT THE POWER AND GROUNDS FOR THE ENTIRE BUS ONE MISSING GROUND CAN TAKE DOWN THE ENTIRE CAN NETWORK ARE AROUND ONE OR TWO MODULES COMMUNITY KEEP FINE ONE MODULE HAS DROPPED THE BUS OFF FIND THAT MODULE THAT'S OFFLINE AND START THERE 2 CHECK THE FAN SPEED FULL SPEED RUNNING WIDE OPEN WITH A NO START NO COMMUNICATION ISSUE YOU HAVE A NETWORK THAT IS IN A FAIL SAFE SO IT'S DEFAULTED TO FAN FULL SPEED THAT TELLS YOU SOMETHING WENT DOWN BEFORE THE CAR STOPPED STARTING 3 POWER GROUND THEN THE BUS IN THAT ORDER EVERY TIME A FULL SCREEN OF U CODES IS THE NETWORK TELLING YOU IT'S IT'S NOT TELLING YOU TO START REPLACING MODULES IT'S TELLING YOU TO FIND WHAT BROKE THE CONVERSATION SEE YOU ON THE NEXT ONE TOO MANY U CODES?

Transcript

U codes all over the screen shouldn't stop you. Here's how to read them. Car comes in, you connect the scan tool. U-codes everywhere, every module seems to have a communication fault. Most texts freeze right then and there. This is actually where diagnosis starts. Network communication faults. They don't mean every module has failed. They mean the modules aren't talking to each other the way that they should. And here's how to read the page full of U codes. First, look for the pattern. If U codes are scattered across every module, the problem is the network, not the modules. Start at the power and grounds for the entire bus. One missing ground can take down the entire CAN network. If the U codes are around one or two modules, keep fine. One module has dropped the bus off. Find that module that's offline and start there. Two, check the fan speed. If you got fans at full speed running wide open with a no start, no communication issue, you have a network that is in a fail safe, so it's defaulted to fan full speed. That tells you something went down before the car stopped starting. Three, power, ground, then the bus in that order. Every time a full screen of U codes is the network telling you it's stressed. It's not telling you to start replacing modules. It's telling you to find what broke the conversation. See you on the next one.
