Siemens PLC training rig
4.8Text-HeavyDirect Question hook
Hook
Siemens PLC training rig... how's it lookin?
@learningautomation
19.3K followers · usually 2.0K views a post
Views
9.7K
Likes
433
Comments
26
Shares
9
Selling · Other Product
Why it worked
The post appeals to a niche audience interested in industrial automation and PLC training by showcasing a hands-on, custom-built educational rig. The detailed breakdown of components and future additions provides value and sparks curiosity within this specific community.
Summary
The creator showcases a Siemens PLC training rig they are building, detailing its various modules and planned additions. The rig is designed for educational purposes, incorporating components like a CPU, HMI, power supply, and input/output modules.
Structure
- 1Introduction of the Siemens PLC training rig
- 2Listing of current modules (CPU, HMI, Power Supply, Relay Module, Digital/Analogue I/O)
- 3Mention of planned additions (conveyor system with motor, contactor, sensors)
- 4Overall purpose as a training tool
Product placement
Siemens S7-1212C CPU: Acts - it is a component of the PLC training rig. Removing it would change what happens in the video.
Siemens KTP400 HMI: Acts - it is a component of the PLC training rig. Removing it would change what happens in the video.
Schneider Electric: Appears - it is a component of the PLC training rig, visible on a small part. Removing it would not change what happens in the video.
On-screen text
Siemens PLC training rig...
how's it lookin?
Original caption
Two more modules to add yet, but then it’s nearly done! Six modules in total: • 24v Power Supply • Siemens S7-1212C CPU • Siemens KTP400 HMI • Relay Module • Digital Inputs & Outputs • Analogue inputs Plus there’s a conveyor system to add too, which has contactor, motor and photo electric sensors for even more interaction on the training.
